Mobile LED Displays, the symbol of the new transmitter in mobile media field, Your ads would through the crowds ,spreading everyone, everywhere, Its revolutionary design make it anti-shock, anti-crash processing.
Pixel Pitch :
2 mmLED Type :
GOBActive Dimensions :
960 x 32 x 139 0mm (double saide)Native Resolution :
480 x 160 pixels (Single side)Overall Dimensions :
1046 x 386 x 139 mmWeight :
17 kgBrightness :
3500-4000 nitMax. consumption :
480 WIngress Protection :
IP 65Mobile LED Displays, the symbol of the new transmitter in mobile media field, Your ads would through the crowds ,spreading everyone, everywhere, Its revolutionary design make it anti-shock, anti-crash processing.

|
MODE |
CRS-2 |
|
|
DISPLAY |
Pixel Pitch |
2 mm |
|
LED Type |
SMD1415+GOB |
|
|
Display Type |
Double side |
|
|
Display Resolution (W x H) |
480 x 160 (Single side) |
|
|
Brightness |
3500~4000 nits |
|
|
Contrast Ratio |
5000:1 |
|
|
Grey Scale |
14 bits |
|
|
Refresh Rate |
≥3840 Hz |
|
|
Viewing Angle (H/V) |
120°/178° |
|
|
Light Lifetime (Typ.) |
100,000 hrs |
|
|
POWER |
Power Supply |
Internal |
|
Input Voltage |
DC 9-36V |
|
|
Power Consumption |
Max. 480W; Avg. 160W |
|
|
MECHANICAL SPECS |
Cabinet Color |
Black (Color can be customized) |
|
Active Dimension |
960 x 320 mm (Single side) |
|
|
Overall Dimension |
1046 x 386 x 139 mm |
|
|
Package Dimension (LxHxD) |
|
|
|
Net Weight |
17 kg |
|
|
Package Weight |
21 kg |
|
|
IP Level |
IP65 |
|
|
Installation |
Car roof luggage rack |
|
|
ENVIRONMENT |
Operating Temperature |
-20℃ ~ 50℃ |
|
Storage Temperature |
-30℃ ~ 80℃ |
|
|
Humidity |
10% ~ 80% RH Non-condensing |
|
CONTROL SYSTEM
|
INTERNAL PLAYER |
Operating System |
Android 11 |
|
Processor |
1.6GH, 4 core CPU,3D GPU, 1GB@600MHz DDR3 high-speed memory |
|
|
Storage |
Built in 8GB (user can use 4G) storage, supports USB expansion, plug and play playback |
|
|
wireless |
Wi-Fi / 4G (scalable) |
|
|
INTERFACE |
WIFI |
Wi-Fi AP+STA (dual Wi-Fi mode), can be used as a hotspot |
|
4G |
Access to Wide Area Network |
|
|
GPS |
Accurate positioning, precise timing, multi screen synchronization |
|
|
Audio output x1 |
1/8 "(3.5mm) TRS plug output |
|
|
USB 2.0 x1 |
Can be used for storage expansion (USB flash drive or SD card, up to 128GB) |
|
|
RJ-45 x1 |
100Mbps input network port access to LAN, cluster control |
|
|
LIGHT |
External brightness sensor, controls screen brightness based on environmental brightness |
|
|
MULTIMEDIA FORMATS |
Video |
Common video formats such as AVI, WMV, MPG, RM/RMVB, VOB, MP4, FLV, etc.; Can support simultaneous playback of multiple videos |
|
Audio |
MPEG-1 Layer III,AAC |
|
|
Image |
bmp、jpg、png |
|
|
Text |
Single line text, static text, multi line scrolling text, office, etc |
|
|
Clock |
Real time clock, multi regional clock display and management |
|
|
OSD |
Supports 32-bit true color OSD, can be displayed at any position, supports video/image text mixing, and can overlay images and text on videos. |
